Wizmax EX580 – Full specification
Specifications
Genral Info
| Brand | Wizmax |
| Model Name | EX580 |
| Series | EX-Series |
| Type | Mechanical (Wireless + Wired) |
| Layout | Full-size (100%) |
| Release Year | 2024 |
| Use Case | Work, Gaming, Productivity |
DESIGN & BUILD
| Frame Material | Aluminum top plate + reinforced plastic base |
| Plate Material | Steel |
| Keycap Material | PBT (Double-shot, shine-through) |
| Color Options | Black, White |
| Dimensions (L × W × H) | 440 × 135 × 40 mm |
| Weight | 1.05 kg |
| Form Factor | Full-size with dedicated numpad |
| Finish | Matte anodized surface with brushed highlights |
SWITCH & TYPING EXPERIENCE
| Switch Type | Mechanical (Hot-swappable) |
| Switch Options | Kailh Red / Brown / White Box Switches |
| Mount Type | Gasket mount with dual-foam dampening |
| Stabilizers | Pre-lubed screw-in stabilizers |
| Typing Angle | Adjustable (3 levels) |
| Key Rollover | Full N-key (wired) / 6-key (Bluetooth) |
| Actuation Force | 45–55g (depending on switch type) |
| Key Travel | 2.0 mm actuation / 4.0 mm total |
| Typing Feel | Crisp, consistent, with subtle cushioning feedback |
PERFORMANCE
| Response Time (Bluetooth) | ~8–10 ms |
| Response Time (Bluetooth) | ~8–10 ms |
| Anti-Ghosting | 100% (NKRO) |
| Input Lag | Negligible (optimized low-latency firmware) |
| Latency Mode | Dedicated Game Mode toggle |
RGB & LIGHTING
| Backlight Type | Per-key RGB |
| LED Orientation | South-facing |
| Lighting Effects | 22 preset effects |
| Custom Effects | Supported (proprietary and VIA/QMK) |
| Brightness Levels | 10-step adjustable |
| Control | Hardware shortcuts + software interface |
SOFTWARE & CUSTOMIZATION
| Firmware | VIA / QMK compatible |
| Key Remapping | Fully programmable |
| Macro Support | Yes |
| Profile Storage | Up to 5 onboard profiles |
| Firmware Update | Supported through USB-C |
| Hotkey Shortcuts | RGB, playback, volume, performance presets |
SOUND & COMFORT
| Acoustic Dampening | Silicone base pad + EVA plate foam |
| Typing Sound Profile | Muted, deep thock with minimal ping |
| Gasket Mount | Gasket mount provides cushioning |
| Noise Reduction | Improved through layered foam design |
| Wrist Rest | Magnetic detachable wrist rest (included) |
| Tilt Feet | Three-level adjustable |
Support and compatibility
| Software Support | Windows, macOS, Linux, Android, iOS |
| Plug-and-Play | VIA cross-platform compatible |
| Layout Options | Windows/macOS keycaps included |
BATTERY & CONNECTIVITY
| Battery Capacity | 5000 mAh |
| Battery Type | Rechargeable lithium polymer |
| Battery Life (No RGB) | Up to 250 hours |
| Battery Life (RGB On) | 80–100 hours |
| Charging Port | USB Type-C |
| Charge Time | Approx. 3.5 hours |
| Wireless Mode | Bluetooth 5.2 |
| Wired Mode | USB-C cable connection |
| Multi-Device Pairing | Yes, up to 4 devices |
| Switch Between Devices | Fn + 1/2/3/4 shortcuts |
| Polling Rate (Wired) | 1000 Hz |
| Polling Rate (Wireless) | 125 Hz |
